Motor hidrolik 26M 42A 1C20 OLEO
OLEO MOTOR
Main image
Click to view image in fullscreen
![]()
Karakteristik pompa roda gigi hidrolik
Produk
26M-42A-1C20 (hydraulic vane motor with heavy duty bearing)
Displacement
42cc
Max. Speed
4.000 rpm
Mounting
SAE - B
Shaft
Diameter: 22,2 mm - SPI
Dimensi SPI
4,75 x 4,75 × 31,8 mm (L x T x P)
Port A-B
SAE 4 bolt flanges (flange F5-10)
Port Drain
1/4 - NPT - 18 THD
Persediaan
SKU
m_100065692
Deskripsi / Motor hidrolik 26M 42A 1C20 OLEO
Karakteristik pompa roda gigi hidrolik
| Produk | 26M-42A-1C20 (hydraulic vane motor with heavy duty bearing) |
|---|---|
| Displacement | 42cc |
| Max. Speed | 4.000 rpm |
| Mounting | SAE - B |
| Shaft | Diameter: 22,2 mm - SPI |
| Dimensi SPI | 4,75 x 4,75 × 31,8 mm (L x T x P) |
| Port A-B | SAE 4 bolt flanges (flange F5-10) |
| Port Drain | 1/4 - NPT - 18 THD |
Informasi Lebih Lanjut
| Jenis koneksi | ISO |
|---|---|
| Negara | Baru |
| Masa garansi, bulan | 12 |
| Negara Asal | Cina |
| Merek | Oleo Motor |
