HHYG-100200S 100Ton Double-Acting Hydraulic Cylinder Stroke 200mm – Silinder Hidrolik Double Acting 100Ton

Double-acting Hydraulic Cylinder HHYG-100200S 100Ton Stroke 200mm, Hydraulic Jack HHYG-100200S, Vertical Split Electric Hydraulic Double Acting Jack, Split Hydraulic Cylinder 100 Ton, Double Hydraulic Cylinder /// 2-way Silinder Hidrolik, Hidrolik Jack 100 ton

Double-acting General Purpose Cylinder 100 Ton Stroke 200mm HHYG-100200S. Versatile, rugged cylinder for tough job site uses and high-cycle industrial uses. Working pressure: 700bar.

Silinder Hidrolik Double-Acting 100 Ton Stroke 200mm HHYG-100200S. Silinder serbaguna yang tangguh untuk penggunaan di lokasi kerja yang berat dan aplikasi industri dengan siklus tinggi. Tekanan kerja: 700 bar.

Fitur Utama Jack Hidrolik HHYG:

• Double-acting for rapid piston retraction.
• High strength alloy steel for durability.
• Chrome plated piston resists wear and corrosion.
• Baked enamel finish for increased corrosion resistance.
• Dust wiper on piston rod reduces contamination.
• Grooved piston rods require no saddle.
• Each cylinder has two HH-II R2 3/8 male half couplers and dust caps.

Spesifikasi Teknis Silinder Hidrolik HHYG-100200S:

• Capacity: 100 tons
• Push Force: 1002 kN
• Pull Force: 557 kN
• Stroke: 200 mm
• Effective Area: 143.1 cm² (push) / 79.5 cm² (pull)
• Oil Capacity: 2863 cm³ (push) / 1590 cm³ (pull)
• Closed Height (A): 389 mm
• Extended Height (B): 589 mm
• Outside Diameter (D): 175 mm
• Inside Diameter (E): 135 mm
• Piston Rod Diameter (F): 90 mm
• Weight (G.W.): 60 kg
• Handle: No
• Recommended Pump: HHB-630B
