Filter saringan pembuangan Hydac seri RF

Filter drain Hydac series RF

• Flow rate: up to 15,000 l/min
• Pressure stages: up to 25 bar
• Connectors: from G½ to DIN DN 300
• Sizes: 30, 60, 110, 160, 240, 330, 450, 580, 660, 950, 1300, 2500, 4000, 5200, 6500, 7800, 15000
• Can be used as a filter for installation on tanks or pipelines

The filter housings are designed according to international standards. They consist of a filter housing and a threaded cover.
Standard equipment:
bypass valve in the element. For RF 450/580, the bypass valve is built into the standard cover.
connection for clogging indicator.

Hydac filters are approved by major industrial plants, with guaranteed retention capacity under high pressure differential (100 bar).
Hydac filters meet the latest advancements in filtration technology and, thanks to their properties, guarantee a significant increase in the service life of hydraulic system components.

Hydac pressure/linear filters are characterized by high filtration capacity and easy maintenance, ensuring safety and cost-effectiveness of equipment operation. With a wide range of linear and mesh technological filters, Hydac can solve practically any tasks in the field of solid and liquid phase separation.
